    Full Color SMD3528 Led Video Wall Screen , Fixed Installation Led Display

    Ask Lasest Price
    Brand Name : Zhongyi
    Model Number : ZFI5
    Certification : CE / RoHS / FCC / ETL / TUV
    Price : negotiation
    Payment Terms : 30% T/T prepayment, 70% T/T balance before shipment
    Supply Ability : 3000 squaremeters per months
    Delivery Time : 26-30 working days after received prepayment
    • Product Details
    • Company Profile

    Full Color SMD3528 Led Video Wall Screen , Fixed Installation Led Display

    Full color P5 SMD3528 Led Video Wall Fixed Installation Screen for Conference​
    P5 indoor screen Quick details
    Contrast 3000:1 Grey 14-16bits
    Refresh>2000HZ
    Cabinet size customized (720p,1080P)
    Nationstar led lamp SMD3528
    MBI Ic from Taiwan
    Meanwell power supplier 5V 60A
    CE & UL certifications
    Magnetic front maintenance led screen

    Classical design and natural tech., reliable quality and great performance.

    Seamless connecting tech., screen flatness error <0.1mm.

    Patented mask, eliminating the dark spots, improving consistency and viewing angle.

    PCB 1.6mm Thickness 4 layers
    Feature
    1. The first level LED chip from Taiwan Epistar
    2. With pure golden wire connection in LED
    3. Grand A row material for module frame and mask
    4. 4 layers PCB and copper plating thickness > 18mil
    5. Stainless steel screws when assembly
    6. Disassembly and assembly are quick and easy
    7. 3 to 5 years warranty
    8 .Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.
    Low Cost of Splicing
    With an aspect ratio of 16:9, panel size is carefully designed so that the HD LED display can be assembled quickly and efficiently into the common display ratio of 4:3 or 16:9
    Indoor fixed led screen has many kinds of installation, like front open design, magnetic led panel design. It can be used all kinds shopping malls, night clubs, conference and so on.
    P5 Indoor Led Screen
    Pixel Pitch(㎜)5mm
    Pixel Density(pixel/㎡)40000
    Pixel Component1R1G1B
    LED ConfigurationSMD3528 Nationstar
    Panel Dimension(W×H)㎜320*160
    Cabinet MaterialSteel
    Cabinet Weight(Kg)50KG
    Brightness(cd/㎡)≥1200
    Color Temperature3200K-9500K
    Viewing Angle(V)140°
    Viewing Angle(H)140°
    Contrast Ratio3000:1
    Max Power Consumption(w/㎡)≤800
    Ave Power Consumption(w/㎡)≤480
    Operating Power SourceAC85~264V(47-63Hz)
    Frame Frequency(Frame/S)60
    Refresh Rate(Hz)≥1200
    Gray LevelRGB65536Grade
    Brightness Adjustment Level256Grade
    Brightness Adjustment ModeManual/Automatic/Programmable
    Control DistanceUTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
    Operating Temp﹣20℃-﹢50℃
    Operating Humidity10%-90%RH
    Protecting RatingIP31
    MTBF>50000h
    LED Life Span>100000h

    Pre-sale service:
    1. Reply enquiries in 16 hours.
    2. Provide unique and professional solutions based on customer's requirement.

    In-sale service:
    1. Tracking report in producing.
    2. Quality test report for every order.

    After-sale service:
    1. Lifetime free maintenance and upgrade.
    2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
