Epistar Chip Nationstar Brand Black Face Led Video Sreen Rental
Type High Contrast 4000HZ Refresh 4K Screen
Detailed introduction:
Best Nationstar SMD2020 Gold Wire lamp
Made in China rental type led screen
Contrast 4000:1, total black face led lamp
4 Layers PCB 1.6mm or above Thickness
Black face SMD2020 / SMD2121 high Contrast 4000:1
14-16 bits large Grey Scale
(P3.91)250*250mm,500*500mm,SMD2121 / SMD2020
(P4.81)250*250mm,500*500mm or 500*1000mm
( P3)192*96mm,576*576mm,SMD2020 SMD2121 Gold wire
(P4)256*128mm, 512*512mm, SMD2020 SMD2121
P5 160*160mm, 640*640mm, SMD2020 SMD2121
P6 192*192mm, 576*576mm, SMD3528
>>>LED brand: Epistar from Taiwan
>>>Power supply: G-energy or Meanwell
>>>Control system:Novastar
Now Indoor p2.6, P2.9 P3.9, P3, P4,P4.8 are hot models in rental
business
Outdoor P3.9, P4.81, p5.95, p6.25,P8,P10 are hot models in outdoor
rental type business
For the magnetic front access led screen(rental type) are not recommended. Because the flatness of total magnetic led screen is not quite
well.One or two screws will be helpful a lot.
Feature:
Durable Die-casting Cabinet
Great Uniformity and Grey Scale
Reliable quality and good performance
Quick Installation, quick Disassemble
Save Labour and Time
Easy and Fast maintenance
Portable rental led display are the superstar in the stage. It show
the beauty of R,G,B colour. Now more and more events,
audio&visual rental companies prefer to use durable rental led
display because of its reliable quality, also amazing effect, which
make the events getting a higher level.
Advanteges
1: Die-casting aluminum adopted to make the cabinet frame is for
ensuring its brilliant hardness,precision and the terrific surface
flatness of entire display.
2: Thickness only with 8cm,and weight with 11kg/cabinet make it
really portable.
3: 2 handy interiocks make the assembly of an entire screen really
easy,which saves a lot of labor cost.
4: Working state indicator at backside makes it easy to know its
working state without opening the backdoor.
5: Good thermal design,excellent heat dissipation even no fans
installation.
| ITEM | P3.91 |
| Pixel Pitch(㎜) | 3.91 |
| Pixel Density(pixel/㎡) | 65536 |
| Pixel Component | 1R1G1B |
| LED Configuration | SMD2121/2020 |
| Panel Dimension(W×H)(mm) | 250*250 |
| Scan Mode | 1/16 |
| Cabinet Dimension(W×H)(mm) | 500*500 |
| Cabinet Material | die-casting aluminum |
| Cabinet Weight Kg | 8 |
| Brightness(cd/㎡) | >1000Nit |
| Color Temperature | 3200K-9500K |
| Viewing Angle(V) | 140° |
| Viewing Angle(H) | 140° |
| Contrast Ratio | 3000:1 |
| Max Power Consumption(w/㎡) | ≤800 |
| Ave Power Consumption(w/㎡) | ≤300 |
| Operating Power Source | AC85~264V(47-63Hz) |
| Frame Frequency(Frame/S) | 60 |
| Refresh Rate(Hz) | ≥1200,≥2880, |
| Gray Level | RGB65536Grade |
| Brightness Adjustment Level | 256Grade |
| Brightness Adjustment Mode | Manual/Automatic/Programmable |
| Control Distance | UTP＜100m；Muti Mode Fiber＜500m；Single Mode Fiber＜10Km |
| Operating Temp | ﹣20℃－﹢50℃ |
| Operating Humidity | 10%－90%RH |
| Protecting Rating | IP31 |
| MTBF | ＞10000h |
| LED Life Span | ＞100000h |
| LED Best View distance | 3m-100m
|
Pre-sale service:
1. Reply enquiries in 16 hours.
2. Provide unique and professional solutions based on customer's
requirement.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Full set of documents free of charge, which including
installation guidance, software operation manual, easy maintenance
manual and control system software CD and so on.
