Brand Name : | Zhongyi |
Model Number : | ZFO10 |
Certification : | CE / RoHS / FCC / ETL / TUV |
Price : | negotiation |
Payment Terms : | 30% T/T prepayment, 70% T/T balance before shipment |
Supply Ability : | 3000 sqms per month |
Delivery Time : | 15-18 days after received prepayment |
•Auto brightness adjustment.
•High refresh rate & High gray.
•Energy saving & Long life span.
•High resolution & Vivid image.
•Durability & Flatness.
ITEM | Ph10 |
Pixel Pitch(㎜) | 10mm |
Pixel Density(pixel/㎡) | 10000 |
PCB | 1.6mm Thickness |
MBI | MBI5124 MBI5024 |
Panel Dimension(W×H)㎜ | 320*160 |
Scan Mode | 1/4 1/2 |
Cabinet Dimension(W×H)㎜ | 960*960 |
Cabinet Material | Iron/Customized |
Brightness(cd/㎡) | ≥6500 |
Color Temperature | 3200K-9500K |
Viewing Angle(V) | 140° |
Viewing Angle(H) | 140° |
Contrast Ratio | 3000:1 |
Max Power Consumption(w/㎡) | 800 |
Ave Power Consumption(w/㎡) | 350 |
Operating Power Source | AC85~264V(47-63Hz) |
Frame Frequency(Frame/S) | 60 |
Refresh Rate(Hz) | ≥1920 |
Gray Level | RGB65536Grade |
Brightness Adjustment Level | 256Grade |
Brightness Adjustment Mode | Manual/Automatic/Programmable |
Control Distance | UTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km |
Operating Temp | ﹣20℃-﹢50℃ |
Operating Humidity | 10%-90%RH |
Protecting Rating | IP65 |
MTBF | >10000h |
LED Life Span | >100000h |
LED Best View distance | 8m-300m |
![]() |
