    1R1G1B IP67 Grid Fixed DIP LED Display , 6000 Nits Outdoor SMD Led Display

    Ask Lasest Price
    Brand Name : Zhongyi
    Model Number : ZF31
    Certification : CE / RoHS / FCC / ETL / TUV
    Price : negotiation
    Payment Terms : 30% T/T prepayment, 70% T/T balance before shipment
    Supply Ability : 3000 squaremeters per months
    Delivery Time : 15-18 days after received prepayment
    • Product Details
    • Company Profile

    1R1G1B IP67 Grid Fixed DIP LED Display , 6000 Nits Outdoor SMD Led Display

    1R1G1B IP67 6000nits P31.25 Grid Fixed DIP LED Display Curtain No Need Air conditioner

    Brief info:
    Very easy installation and maintenance, ultra-slim frame structure can achieve front and rear maintain according to the using environment which can save a lot maintain cost.
    Led curtain display thickness is only 70mm, 2cm thickness of front maintain structure, 18kg/sqm of led curtain display which lighter 30-60% to the traditional led display. Reduce the construction load efficiency and reduce installation costs.
    Aluminum alloy cabinet structure with high strength, no deformation, anti-corrosion characteristic. Adapt to a variety of climatic conditions, especially high temperature, high humidity environment.
    Led curtain display adopted integrated, modular design achieve module or cabinet assemble and disassemble function.
    Architectural contour and wall structure does not to be changed due to its lightweight and hollow design. It is also good for lighting.
    Led curtain led display not only features lightweight structure but also has beautiful appearance which can be installed on the wall without any change.
    Low temperature power supplier
    Great reliable quality
    -35℃ -- +80℃
    80% heat sinking IP67
    Quick introduction:
    Cost savings of Air conditioner
    Cost savings 80% of maintain operation
    Cost savings 70% of electricity
    Cost savings 70% of steel structure
    Cost savings 80% of labour
    Cost savings 75% of transportation
    Fast maintenance
    Patented design for 3 minutes/sqm
    Easy to achieve front / rear maintenance

    Special only led Grid Screen
    Steel weight 10KG/sqm only, equal 15% of traditional outdoor led screen steel Cabinet

    Transparency 40%-80%
    Look like Screenless

    Quick installation
    Finish installation 10 seconds per sqm

    Specification parameter P31.25 outdoor Led Curtain Fixed led Display

    Tube colorSpecificationsIndicators (typical values, specific to selected lamps)
    RdomesticWavelength: 618-630nm, brightness 870mcd (20mA)
    GdomesticWavelength: 518-538nm, brightness 1680mcd (10mA)
    BdomesticWavelength: 460-480nm, brightness 380mcd (10mA)
    Product model31.25mm-31.25mm
    Horizontal spacing(mm) Vertical spacing(mm)31.25mm 31.25mm
    Pixel compositionDIP346
    Resolution (dot/㎡)4096
    Unit cabinet dots1024
    Pixel per Unit(dots)32(W)x32(H)
    Color Grayscale (Bit)14
    Brightness(CD/㎡)≥6000cd
    Contrast1:1600
    Color temperature6500-9300k
    (Brightness adjust)0-255
    Horizontal viewing angle(°) Vertical viewing angle(°)≥110° ≥50°
    SupportDVI HDMI
    Max Consumption(W/㎡)450
    Average power consumption(W/㎡)135
    Unit cabinet Weight (kg/pcs)10.0
    Cabinet Weight (kg/㎡)20.0
    Frame Weight (kg/㎡)8.0
    Unit cabinet thickness (cm)6.7
    Frame thickness (cm)6.0
    Installation thickness (cm)12.7
    Strips width(mm)9.8
    Transparent Rate(%)40%
    Frame rate(HZ)60
    Pixel uncontrol rate<1/10000


    Pre-sale service:
    1. Reply enquiries in 16 hours.
    2. Market research and forecast for customer.

    In-sale service:
    1. Tracking report in producing.
    2. Quality test report for every order.
    After-sale service:
    1. Lifetime free maintenance and upgrade.
    2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
