    Outdoor Led Billboard Display Screen High Resolution Waterproof P10 Steel Cabinet

    Ask Lasest Price
    Brand Name : Zhongyi
    Model Number : ZFO10
    Certification : CE / RoHS / FCC / ETL / TUV
    Price : negotiation
    Supply Ability : 30% T/T prepayment, 70% T/T balance before shipment
    Delivery Time : 15-18 working days after received prepayment
    • Product Details
    • Company Profile

    Outdoor Led Billboard Display Screen High Resolution Waterproof P10 Steel Cabinet

    Video wall outdoor led billboard display screen high resolution waterproof P10 steel cabinet 6500nits


    Feature:

    With 85-264VAC large scale switching power supply input, typical value: 110VAC/220VAC.
    Pixel pitch is 0.39 inch (10mm) for outdoor usage;
    Popular DIP346 led type, 1 red 1 green and 1 blue, traditional dip type led;
    Cabinet resolution are W 96 x H 96 dots, cabinet size is W 37.8 x H 37.8 inch;
    More than 960Hz refreshing frequency and 14bit grey scale;
    110 °Horizontal viewing angle and 55° vertical viewing angle;
    Driving method is 1/4 can constant current;
    Physical density: 929dots per square feet (10000 dots per square meters);
    Module pixel configuration of W 32 × H 16 dots;
    Module size is W 12.6 X H 6.3 inch (W 320 × H 160 mm);

    Detailed Description:

    1. High brightness DIP346 Led lamps are adopted, so the led screen has high brightness of 7000nits and you can see clearly from a long distance even in direct sunlight;
    2. Static scanning technology and module design technology are adopted to offer higher reliability and stability;


    Popular Application:

    Commercial centers, railway stations and large-scale entertainment plazas;


    1. Fast maintanance
    2. Adopt grating air convection cooling system,good heat dissapation
    3. Strict waterproof gurantee of quality IP65

    4. Stablity quality and lifetime maintenance

    5. DIP346 led screen waterproof

    6. Anti-corrosion, UV resistant

    7. Available - texts, pics, video advertising contents

    8. Lamp board and driver board separate

    P10 outdoor fixed led display has DIP and SMD lamp, two soution. Each has its own advantages.

    P10 Outdoor LED Display

    ITEMP10
    Pixel Pitch(㎜)10
    Pixel Density(pixel/㎡)10000
    Pixel Component1R1G1B
    LED ConfigurationSMD3535 DIP346
    Panel Dimension(W×H)㎜320*160
    Scan Mode1/4 (or 1/2)
    Cabinet Dimension(W×H)㎜960*960/Customized
    Cabinet MaterialIron/Customized
    Brightness(cd/㎡)≥6000 ( or ≥7000)
    Color Temperature3200K-9500K
    Viewing Angle(V)140°
    Viewing Angle(H)140°
    Contrast Ratio3000:1
    Max Power Consumption(w/㎡)750
    Ave Power Consumption(w/㎡)300
    Operating Power SourceAC85~264V(47-63Hz)
    Frame Frequency(Frame/S)60
    Refresh Rate(Hz)≥1200
    Gray LevelRGB65536Grade
    Brightness Adjustment Level256Grade
    Brightness Adjustment ModeManual/Automatic/Programmable
    Control DistanceUTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
    Operating Temp﹣20℃-﹢50℃
    Operating Humidity10%-90%RH
    Protecting RatingIP65
    MTBF>10000h
    LED Life Span>100000h
    LED Best View distance8m-300m

    Pre-sale service:
    1. Reply enquiries in 16 hours.
    2. Market research and forecast for customer.

    In-sale service:
    1. Tracking report in producing.
    2. Quality test report for every order.
    3. Photos and videos as per customer's requirement.

    After-sale service:
    1. Lifetime free maintenance and upgrade.
    2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
